Turning tools | Indexable turning inserts CoroTurn® 107, insert for turning. D-style insert (Rhombic 55°) Imperial (inch) P M K 1625 1625 1625 Ordering code ANSI SSC LE S RE IC D1 [inch] [inch] [inch] [inch] [inch] NEW DCMT 2(1.5)1-PM ○ ○ ○ 1/4 0.289 0.094 0.016 0.250 0.110 NEW DCMT 2(1.5)2-PM ○ ○ ○ 1/4 0.274 0.094 0.031 0.250 0.110 ○ ○ ○ 3/8 0.442 0.156 0.016 0.375 0.173 PM NEW DCMT 3(2.5)1-PM ○ ○ ○ 3/8 0.426 0.156 0.031 0.375 0.173 Medium NEW DCMT 3(2.5)2-PM NEW DCMT 3(2.5)3-PM ○ ○ ○ 3/8 0.411 0.156 0.047 0.375 0.173 NEW DCMT 2(1.5)1-UM ○ ○ ○ 1/4 0.289 0.094 0.016 0.250 0.110 ○ ○ ○ 3/8 0.442 0.156 0.016 0.375 0.173 UM NEW DCMT 3(2.5)1-UM NEW DCMT 3(2.5)2-UM ○ ○ ○ 3/8 0.426 0.156 0.031 0.375 0.173 ● = First choice ○ = Good choice 33
