Инструменты расточки | Внешние инструменты расточки
CoroTurn® 107, режущий узел для расточки
Coromant Capto® - система подвода СОЖ
| Общие значения параметров |
|---|
| RMPX [градус] |
| 90.00 |
Метрическая система (мм)
| Артикул заказа | SSC | DCONMS [мм] | LF [мм] | WF [мм] | OHX [мм] | CNSC [бар] | CP | TQ [Нм] | MIID |
|---|---|---|---|---|---|---|---|---|---|
| HT06-SRDCN-00100-10XC | 10 | 63.00 | 100.00 | 5.00 | 100.0 | 1 | 150 | 3.0 | RCMT 10 T3 MP |
| HT06-SRDCN-00100-12XC | 12 | 63.00 | 100.00 | 6.00 | 100.0 | 1 | 150 | 3.0 | RCMT 12 04 MP |
| HT06-SRDCN-00100-16XC | 16 | 63.00 | 100.00 | 8.00 | 100.0 | 1 | 150 | 6.4 | RCMT 16 06 MP |
| HT10-SRDCN-00100-10XC | 10 | 100.00 | 100.00 | 5.00 | 100.0 | 1 | 150 | 3.0 | RCMT 10 T3 MP |
| HT10-SRDCN-00100-12XC | 12 | 100.00 | 100.00 | 6.00 | 100.0 | 1 | 150 | 3.0 | RCMT 12 04 MP |
| HT10-SRDCN-00100-16XC | 16 | 100.00 | 100.00 | 8.00 | 100.0 | 1 | 150 | 6.4 | RCMT 16 06 MP |
П = правое вращение, Л = левое вращение
Coromant Capto® - система подвода СОЖ
| Общие значения параметров | ||
|---|---|---|
| RMPX [градус] | PSIR [градус] | BAMS [градус] |
| 50.00 | -3.00 | 45.00 |
Метрическая система (мм)
| Артикул заказа | SSC | DCONMS [мм] | LF [мм] | KAPR 1 [градус] | KAPR 2 [градус] | OHX [мм] | CNSC [бар] | CP | TQ [Нм] | MIID | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| HT06-SVMBL-00130-16C | 16 | 63.00 | 130.00 | 93.0 | — | 52.0 | 130.0 | 1 | 150 | 3.0 | VBMT 16 04 08 |
| HT10-SVMBL-00130-16C | 16 | 100.00 | 130.00 | 93.0 | — | 52.0 | 130.0 | 1 | 150 | 3.0 | VBMT 16 04 08 |
П = правое вращение, Л = левое вращение
