Инструменты расточки | Внутренние инструменты расточки
CoroTurn® 107, режущая головка для расточки
Пластина стиля: CCMT
| Общие значения параметров |
|---|
| PSIR [градус] |
| -5.00 |
Метрическая система (мм)
| Артикул заказа | SSC | DMIN 1 [мм] | DCONMS [мм] | LF [мм] | WF [мм] | KAPR 1 [градус] | OHX [мм] | CNSC [бар] | CP | TQ [Нм] | MIID | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SL-SCLCL-16-06-11D | 06 | 20.0 | 16.00 | 20.00 | 11.00 | 95.0 | — | 20.0 | 8 | 40 | 0.9 | CCMT 06 02 04 |
| SL-SCLCL-20-09-13D | 09 | 25.0 | 20.00 | 20.00 | 13.00 | 95.0 | — | 20.0 | 8 | 40 | 3.0 | CCMT 09 T3 08 |
| SL-SCLCR-16-06-11D | 06 | 20.0 | 16.00 | 20.00 | 11.00 | 95.0 | — | 20.0 | 8 | 40 | 0.9 | CCMT 06 02 04 |
| SL-SCLCR-20-09-13D | 09 | 25.0 | 20.00 | 20.00 | 13.00 | 95.0 | — | 20.0 | 8 | 40 | 3.0 | CCMT 09 T3 08 |
П = правое вращение, Л = левое вращение
Пластина стиля: DCMT
| Общие значения параметров | |
|---|---|
| RMPX [градус] | PSIR [градус] |
| 27.00 | -3.00 |
Метрическая система (мм)
| Артикул заказа | SSC | DMIN 1 [мм] | DCONMS [мм] | LF [мм] | WF [мм] | KAPR 1 [градус] | OHX [мм] | CNSC [бар] | CP | TQ [Нм] | MIID | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SL-SDUCL-16-07-11D | 07 | 20.0 | 16.00 | 20.00 | 11.00 | 93.0 | — | 20.0 | 8 | 40 | 0.9 | DCMT 07 02 04 |
| SL-SDUCL-20-11-13D | 11 | 25.0 | 20.00 | 20.00 | 13.00 | 93.0 | — | 20.0 | 8 | 40 | 3.0 | DCMT 11 T3 08 |
| SL-SDUCR-16-07-11D | 07 | 20.0 | 16.00 | 20.00 | 11.00 | 93.0 | — | 20.0 | 8 | 40 | 0.9 | DCMT 07 02 04 |
| SL-SDUCR-20-11-13D | 11 | 25.0 | 20.00 | 20.00 | 13.00 | 93.0 | — | 20.0 | 8 | 40 | 3.0 | DCMT 11 T3 08 |
П = правое вращение, Л = левое вращение
