Инструменты расточки | Внешние инструменты расточки
T-Max®, режущий узел для расточки
Coromant Capto® - система подвода СОЖ
| Общие значения параметров |
|---|
| RMPX [градус] |
| 45.00 |
Метрическая система (мм)
| Артикул заказа | SSC | DMIN 1 [мм] | DMIN 2 [мм] | DCONMS [мм] | LF [мм] | WF [мм] | OHX [мм] | CNSC [бар] | CP | TQ [Нм] | MIID |
|---|---|---|---|---|---|---|---|---|---|---|---|
| НОВ C5-CRSCL-35060-06A | 06 | 120.0 | 220.0 | 50.00 | 60.00 | 35.00 | 60.0 | 3 | 150 | 1.2 | RCGX 06 06 00 |
| НОВ C5-CRSCR-35060-06A | 06 | 120.0 | 220.0 | 50.00 | 60.00 | 35.00 | 60.0 | 3 | 150 | 1.2 | RCGX 06 06 00 |
| НОВ C6-CRSCL-45065-06A | 06 | 110.0 | 220.0 | 63.00 | 65.00 | 45.00 | 65.0 | 3 | 150 | 1.2 | RCGX 06 06 00 |
| НОВ C6-CRSCR-45065-06A | 06 | 110.0 | 220.0 | 63.00 | 65.00 | 45.00 | 65.0 | 3 | 150 | 1.2 | RCGX 06 06 00 |
П = правое вращение, Л = левое вращение
