Инструменты расточки | Внешние инструменты расточки
T-Max® P, режущий узел для расточки
Конструкция с винтовым зажимом
| Общие значения параметров | |
|---|---|
| PSIR [градус] | BAMS [градус] |
| -5.00 | 45.00 |
Метрическая система (мм)
| Артикул заказа | SSC | DMIN 2 [мм] | DCONMS [мм] | LF [мм] | KAPR 1 [градус] | OHX [мм] | CNSC [бар] | CP | TQ [Нм] | MIID | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| HT06-PCMNN-00115-12C | 12 | 240.0 | 63.00 | 115.00 | 95.0 | — | 115.0 | 1 | 150 | 5.0 | CNMG 12 04 08 |
| HT10-PCMNN-00115-12C | 12 | 240.0 | 100.00 | 115.00 | 95.0 | — | 115.0 | 1 | 150 | 5.0 | CNMG 12 04 08 |
П = правое вращение, Л = левое вращение
Конструкция с жёстким зажимом
| Общие значения параметров | ||
|---|---|---|
| RMPX [градус] | PSIR [градус] | BAMS [градус] |
| 27.00 | -3.00 | 45.00 |
Метрическая система (мм)
| Артикул заказа | SSC | DCONMS [мм] | LF [мм] | WF [мм] | KAPR 1 [градус] | KAPR 2 [градус] | OHX [мм] | CNSC [бар] | CP | TQ [Нм] | MIID | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| HT06-DDMNL-00130-15C | 15 | 63.00 | 130.00 | 0.98 | 93.0 | — | 32.0 | 130.0 | 1 | 150 | 3.9 | DNMG 15 06 08 |
| HT10-DDMNL-00130-15C | 15 | 100.00 | 130.00 | 0.98 | 93.0 | — | 32.0 | 130.0 | 1 | 150 | 3.9 | DNMG 15 06 08 |
П = правое вращение, Л = левое вращение
