Инструменты для точения | Индексируемые пластины для точения
CoroTurn® 111, пластина для точения
Пластина D-образной формы (ромбическая 55°)
Метрическая система (мм)
| Код заказа | Оценка | SSC [мм] | LE [мм] | S [мм] | RE [мм] | IC [мм] | D1 [мм] | ||
|---|---|---|---|---|---|---|---|---|---|
| Средняя обработка (PM) | |||||||||
| NEW DPMT 07 02 04-PM | ● | ● | ● | 07 | 7.4 | 2.38 | 0.4 | 6.35 | 2.80 |
| NEW DPMT 11 T3 04-PM | ● | ● | ● | 11 | 11.2 | 3.97 | 0.4 | 9.52 | 4.40 |
Дюймовая система
| Код заказа ANSI | Оценка | SSC [дюйм] | LE [дюйм] | S [дюйм] | RE [дюйм] | IC [дюйм] | D1 [дюйм] | ||
|---|---|---|---|---|---|---|---|---|---|
| Средняя обработка (PM) | |||||||||
| NEW DPMT 2(1.5)1-PM | ● | ● | ● | 1/4 | 0.289 | 0.094 | 0.016 | 0.250 | 0.110 |
| NEW DPMT 3(2.5)1-PM | ● | ● | ● | 3/8 | 0.442 | 0.156 | 0.016 | 0.375 | 0.173 |
