Инструменты расточки | Внешние инструменты расточки
CoroTurn® TR, режущий узел для расточки
HSK-T - система подвода СОЖ
| Общие значения параметров | ||
|---|---|---|
| RMPX [градус] | PSIR [градус] | BAMS [градус] |
| 30.00 | -3.00 | 45.00 |
Метрическая система (мм)
| Артикул заказа | SSC | DCONMS [мм] | LF [мм] | KAPR 1 [градус] | KAPR 2 [градус] | OHX [мм] | CNSC [бар] | CP | TQ [Нм] | MIID | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| HT06-TR-D13MCL-00130C | 13 | 63.00 | 130.00 | 93.0 | — | 32.0 | 130.0 | 1 | 150 | 3.0 | TR-DC1308 |
| HT10-TR-D13MCL-00130C | 13 | 100.00 | 130.00 | 93.0 | — | 32.0 | 130.0 | 1 | 150 | 3.0 | TR-DC1308 |
П = правое вращение, Л = левое вращение
HSK-T - система подвода СОЖ
| Общие значения параметров | ||
|---|---|---|
| RMPX [градус] | PSIR [градус] | BAMS [градус] |
| 50.00 | -3.00 | 45.00 |
Метрическая система (мм)
| Артикул заказа | SSC | DCONMS [мм] | LF [мм] | KAPR 1 [градус] | KAPR 2 [градус] | OHX [мм] | CNSC [бар] | CP | TQ [Нм] | MIID | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| HT06-TR-V13MBL-00130C | 13 | 63.00 | 130.00 | 93.0 | — | 52.0 | 130.0 | 1 | 150 | 2.0 | TR-VB1308 |
| HT10-TR-V13MBL-00130C | 13 | 100.00 | 130.00 | 93.0 | — | 52.0 | 130.0 | 1 | 150 | 2.0 | TR-VB1308 |
П = правое вращение, Л = левое вращение
