Инструменты с цельным профилем | Инструменты для сверления
CoroDrill® Dura 462, микросверло из твердого сплава для обработки различных материалов
Внешняя подача СОЖ
Стандартные значения параметров
ПОКРЫТИЕ: PVD TiAlN
Метрическая система (мм)
| Артикул | P X0BM |
M X0BM |
K X0BM |
N X0BM |
S X0BM |
O X0BM |
DC [мм] |
LU [мм] |
LF [мм] |
OAL [мм] |
DCONMS [мм] |
SIG [град] |
LCF [мм] |
PL [мм] |
ULDR | TCDCON | TCHA |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 462.1-0300-009A0-XM | ● | ● | ● | ● | ● | ● | 3.00 | 9.50 | 37.30 | 38.00 | 3.00 | 130.00 | 14.00 | 0.70 | 3.17 | h6 | JS7 |
● = Первый выбор ○ = Хороший выбор
Внешняя подача СОЖ
Метрическая система (мм)
| Артикул | P X0BU |
M X0BU |
K X0BU |
N X0BU |
S X0BU |
O X0BU |
DC [мм] |
LU [мм] |
LF [мм] |
OAL [мм] |
DCONMS [мм] |
SIG [град] |
LCF [мм] |
PL [мм] |
ULDR | TCDCON | TCHA |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 462.1-0300-009A0-XM | ● | ● | ● | ● | ● | ● | 3.00 | 9.50 | 37.30 | 38.00 | 3.00 | 130.00 | 14.00 | 0.70 | 3.17 | h6 | JS7 |
● = Первый выбор ○ = Хороший выбор
