Резцы | Сменные пластины для точения
T-Max® P, пластина для точения
Пластина типа W (треугольник 80°)
Метрическая система (мм)
Финишная обработка
| Код заказа | P | M | K | SSC | LE | S | RE | IC | D1 |
|---|---|---|---|---|---|---|---|---|---|
| 1625 | 1625 | 1625 | |||||||
| NEW WNMG 06 04 04-WF | ○ | ○ | ○ | 06 | 6.1 | 4.76 | 0.4 | 9.52 | 3.81 |
| NEW WNMG 06 04 08-WF | ○ | ○ | ○ | 06 | 5.7 | 4.76 | 0.8 | 9.52 | 3.81 |
| NEW WNMG 08 04 04-WF | ○ | ○ | ○ | 08 | 8.3 | 4.76 | 0.4 | 12.70 | 5.16 |
| NEW WNMG 08 04 08-WF | ○ | ○ | ○ | 08 | 7.9 | 4.76 | 0.8 | 12.70 | 5.16 |
| NEW WNMG 08 04 08-WL | ○ | ○ | 08 | 7.9 | 4.76 | 0.8 | 12.70 | 5.16 | |
Средний
| Код заказа | P | M | K | SSC | LE | S | RE | IC | D1 | |
|---|---|---|---|---|---|---|---|---|---|---|
| 1625 | 1625 | 1625 | ||||||||
| NEW WNMG 08 04 08-WM | ○ | ○ | ○ | 08 | 7.9 | 4.76 | 0.8 | 12.70 | 5.16 | |
● = Первый выбор ○ = Хороший выбор
