Milling tools | Groove milling tools CoroMill® 331, insert for side and face milling Optimised for non-ferrous materials, ISO N Metric (mm) P M N S 1230 1230 1230 1230 Ordering code SSC S BS RE W1 LE APMX KRINS HAND [mm] [mm] [mm] [mm] [mm] [mm] [deg] N331.1A-04 35 05H-NL ● ○ ○ ○ 04 3.50 0.2 0.5 9.5 4.6 4.6 90.00 Neutral N331.1A-05 45 08H-NL ● ○ ○ ○ 05 4.45 0.8 0.8 9.5 5.7 5.7 90.00 Neutral Light N331.1A-08 45 08H-NL ● ○ ○ ○ 08 NL 4.45 0.9 0.8 9.5 7.7 7.7 90.00 Neutral N331.1A-11 50 08H-NL ● ○ ○ ○ 11 4.95 1.3 0.8 11.5 10.7 10.7 90.00 Neutral N331.1A-14 50 08H-NL ● ○ ○ ○ 14 4.95 1.1 0.8 11.5 13.7 13.7 90.00 Neutral ● = First choice ○ = Good choice 215
