Turning tools | Indexable turning inserts T-Max® P, insert for turning C-style insert (Rhombic 80°) Metric (mm) P M 1625 1625 Ordering code SSC LE S RE IC D1 [mm] [mm] [mm] [mm] [mm] NEW CNMG 12 04 04-LC ○ ○ 12 12.5 4.76 0.4 12.70 5.16 Finishing ○ ○ 12 LC NEW CNMG 12 04 08-LC 12.1 4.76 0.8 12.70 5.16 ● = First choice ○ = Good choice Imperial (inch) P M 1625 1625 Ordering code ANSI SSC LE S RE IC D1 [inch] [inch] [inch] [inch] [inch] NEW CNMG 431-LC ○ ○ 1/2 0.492 0.188 0.016 0.500 0.203 Finishing ○ ○ 1/2 0.476 0.188 0.031 0.500 0.203 LC NEW CNMG 432-LC ● = First choice ○ = Good choice 13
