Фрезерные инструменты | Плечевые фрезы
CoroMill® 390, пластина для фрезерования
Оптимизирована для стали, ISO P
Средний режим PM и PMR
Метрические размеры (мм)
| Артикул | Выбор | S (мм) | BS (мм) | RE (мм) | W1 (мм) | LE (мм) | APMX (мм) | KRINS (град) | Направление |
|---|---|---|---|---|---|---|---|---|---|
| R390-18 06 08M-PM | ● (Первый выбор) | 6.33 | 1.1 | 0.8 | 11.0 | 15.4 | 16.0 | 90.00 | Правое вращение |
| R390-18 06 12M-PM | ● (Первый выбор) | 6.33 | 1.1 | 1.2 | 11.0 | 15.4 | 16.0 | 90.00 | Правое вращение |
| R390-18 06 16M-PM | ● (Первый выбор) | 6.33 | 1.1 | 1.6 | 11.0 | 15.4 | 16.0 | 90.00 | Правое вращение |
| R390-18 06 20M-PM | ● (Первый выбор) | 6.33 | 0.5 | 2.0 | 11.0 | 15.4 | 16.0 | 90.00 | Правое вращение |
| R390-18 06 31M-PM | ● (Первый выбор) | 6.33 | 0.5 | 3.1 | 11.0 | 15.4 | 16.0 | 90.00 | Правое вращение |
| R390-18 06 12M-PMR | ● (Первый выбор) | 6.33 | 0.3 | 1.2 | 11.0 | 15.4 | 17.0 | 90.00 | Правое вращение |
