Инструменты отрезки и нарезания канавок | CoroCut® 2
CoroCut® 2, пластина для профилирования
Нейтральная версия. Средняя обработка
| Артикул | SSC | CW [мм] | RE [мм] | APMX [град] | AN [мм] | CWTOLL [мм] | CWTOLU [мм] | RETOLL [мм] | RETOLU [мм] |
|---|---|---|---|---|---|---|---|---|---|
| C2I-F2N-0300-RM | F | 3.00 | 1.5 | 1.3 | 7.0 | -0.040 | 0.040 | -0.050 | 0.050 |
| C2I-G2N-0400-RM | G | 4.00 | 2.0 | 1.8 | 7.0 | -0.040 | 0.040 | -0.050 | 0.050 |
| C2I-H2N-0400-RM | H | 4.00 | 2.0 | 1.8 | 7.0 | -0.045 | 0.045 | -0.050 | 0.050 |
| C2I-H2N-0500-RM | H | 5.00 | 2.5 | 2.3 | 7.0 | -0.045 | 0.045 | -0.050 | 0.050 |
| C2I-J2N-0600-RM | J | 6.00 | 3.0 | 2.8 | 7.0 | -0.045 | 0.045 | -0.050 | 0.050 |
| C2I-L2N-0800-RM | L | 8.00 | 4.0 | 3.8 | 7.0 | -0.050 | 0.050 | -0.100 | 0.100 |
● = Первый выбор ○ = Хороший выбор
