Инструменты отрезки и нарезания канавок | CoroCut® 2
CoroCut® 2, пластина для отрезки
Правая версия
Метрическая система (мм)
| Артикул заказа | SSC | CW [мм] | REL [мм] | RER [мм] | PSIRR [градус] | AN [градус] | CWTOLL [мм] | CWTOLU [мм] | RETOLL [мм] |
|---|---|---|---|---|---|---|---|---|---|
| C2I-F2R-0250-0503-CR | F | 2.50 | 0.30 | 0.30 | 5.0 | 7.0 | -0.050 | 0.050 | -0.100 |
Черновая обработка
| Артикул заказа | SSC | CW [мм] | REL [мм] | RER [мм] | PSIRR [градус] | AN [градус] | CWTOLL [мм] | CWTOLU [мм] | RETOLL [мм] |
|---|---|---|---|---|---|---|---|---|---|
| C2I-G2R-0300-0503-CR | G | 3.00 | 0.30 | 0.30 | 5.0 | 7.0 | -0.050 | 0.050 | -0.100 |
| C2I-H2R-0400-0503-CR | H | 4.00 | 0.30 | 0.30 | 5.0 | 7.0 | -0.050 | 0.050 | -0.100 |
| C2I-J2R-0500-0504-CR | J | 5.00 | 0.40 | 0.40 | 5.0 | 7.0 | -0.050 | 0.050 | -0.100 |
● = Первый выбор, ○ = Хороший выбор
