Резцы | Сменные пластины для точения
CoroTurn® 107, пластина для точения
Пластина типа D (ромб 55°)
Метрическая система (мм)
Финишная обработка
| Код заказа | P | M | K | SSC | LE | S | RE | IC | BN | D1 |
|---|---|---|---|---|---|---|---|---|---|---|
| 1625 | 1625 | 1625 | ||||||||
| NEW DCMX 07 02 04-WF | ○ | ○ | ○ | 07 | 7.4 | 2.38 | 0.4 | 6.35 | 0.07 | 2.80 |
| NEW DCMX 07 02 08-WF | ○ | ○ | ○ | 07 | 7.0 | 2.38 | 0.8 | 6.35 | 0.07 | 2.80 |
| NEW DCMX 11 T3 04-WF | ○ | ○ | ○ | 11 | 11.2 | 3.97 | 0.4 | 9.52 | 0.07 | 4.40 |
| NEW DCMX 11 T3 08-WF | ○ | ○ | ○ | 11 | 10.8 | 3.97 | 0.8 | 9.52 | 0.07 | 4.40 |
Средний
| Код заказа | P | M | K | SSC | LE | S | RE | IC | BN | D1 |
|---|---|---|---|---|---|---|---|---|---|---|
| 1625 | 1625 | 1625 | ||||||||
| NEW DCMX 11 T3 04-WM | ○ | ○ | ○ | 11 | 11.2 | 3.97 | 0.4 | 9.52 | 0.12 | 4.40 |
| NEW DCMX 11 T3 08-WM | ○ | ○ | ○ | 11 | 10.8 | 3.97 | 0.8 | 9.52 | 0.12 | 4.40 |
● = Первый выбор ○ = Хороший выбор
Имперская система (дюймы)
Финишная обработка
| Код заказа ANSI | P | M | K | SSC | LE | S | RE | IC | BN | D1 |
|---|---|---|---|---|---|---|---|---|---|---|
| 1625 | 1625 | 1625 | ||||||||
| NEW DCMX 2(1.5)1-WF | ○ | ○ | ○ | 1/4 | 0.289 | 0.094 | 0.016 | 0.250 | 0.003 | 0.110 |
| NEW DCMX 2(1.5)2-WF | ○ | ○ | ○ | 1/4 | 0.274 | 0.094 | 0.031 | 0.250 | 0.003 | 0.110 |
| NEW DCMX 3(2.5)1-WF | ○ | ○ | ○ | 3/8 | 0.442 | 0.156 | 0.016 | 0.375 | 0.003 | 0.173 |
| NEW DCMX 3(2.5)2-WF | ○ | ○ | ○ | 3/8 | 0.426 | 0.156 | 0.031 | 0.375 | 0.003 | 0.173 |
Средний
| Код заказа ANSI | P | M | K | SSC | LE | S | RE | IC | BN | D1 |
|---|---|---|---|---|---|---|---|---|---|---|
| 1625 | 1625 | 1625 | ||||||||
| NEW DCMX 3(2.5)1-WM | ○ | ○ | ○ | 3/8 | 0.442 | 0.156 | 0.016 | 0.375 | 0.005 | 0.173 |
| NEW DCMX 3(2.5)2-WM | ○ | ○ | ○ | 3/8 | 0.426 | 0.156 | 0.031 | 0.375 | 0.005 | 0.173 |
● = Первый выбор ○ = Хороший выбор
