Резцы | Сменные пластины для точения
T-Max® P, пластина для точения
Пластина типа D (ромб 55°)
Метрическая система (мм)
Средний
| Код заказа | P | M | K | SSC | LE | S | RE | IC | D1 |
|---|---|---|---|---|---|---|---|---|---|
| 1625 | 1625 | 1625 | |||||||
| NEW DNMG 11 04 08-PM | ○ | ○ | ○ | 11 | 10.8 | 4.76 | 0.8 | 9.52 | 3.81 |
| NEW DNMG 15 04 08-PM | ○ | ○ | ○ | 15 | 14.7 | 4.76 | 0.8 | 12.70 | 5.16 |
| NEW DNMG 15 06 08-PM | ○ | ○ | ○ | 15 | 14.7 | 6.35 | 0.8 | 12.70 | 5.16 |
● = Первый выбор ○ = Хороший выбор
Имперская система (дюймы)
| Код заказа ANSI | P | M | K | SSC | LE | S | RE | IC | D1 |
|---|---|---|---|---|---|---|---|---|---|
| 1625 | 1625 | 1625 | |||||||
| NEW DNMG 332-PM | ○ | ○ | ○ | 3/8 | 0.426 | 0.188 | 0.031 | 0.375 | 0.150 |
| NEW DNMG 432-PM | ○ | ○ | ○ | 1/2 | 0.579 | 0.188 | 0.031 | 0.500 | 0.203 |
| NEW DNMG 442-PM | ○ | ○ | ○ | 1/2 | 0.579 | 0.250 | 0.031 | 0.500 | 0.203 |
● = Первый выбор ○ = Хороший выбор
