CoroCut® QD, blade for parting
Spring clamp design, double-sided, curved reinforced, neutral version.
Metric (mm)
| Ordering code | SSC | CDX | OHX | OHN | H | LF | WF | HF | CUTDIA |
| [mm] | [mm] | [mm] | [mm] | [mm] | [mm] | [mm] | [mm] | ||
| QD-NR2E26-21D | E | 26.0 | 50.0 | 26.0 | 25.90 | 110.00 | 2.60 | 21.4 | 52 |
SSC = To correspond with SSC on insert Spring clamp design, single-sided, linear reinforced, right-hand version.
Metric (mm)
| Ordering code | SSC | CDX | OHX | OHN | H | LF | WF | HF |
| [mm] | [mm] | [mm] | [mm] | [mm] | [mm] | [mm] | ||
| QD-RL1G33-25A | G | 33.0 | 50.0 | 33.0 | 31.90 | 110.00 | 8.32 | 25.0 |
| QD-RR1G33-25A | G | 33.0 | 50.0 | 33.0 | 31.90 | 110.00 | 2.67 | 25.0 |
SSC = To correspond with SSC on insert
