CoroCut® 2, insert for parting
Neutral version
CDX AN
LIG REL CW RER
Metric (mm)
| P | M | K | N | S | |||||||||
| Ordering code | 1225 1135 3115 1145 4425 | 1205 1225 1135 1145 | 1225 | 1135 3115 | 4425 | 1205 1225 | 1205 1225 1135 | 1145 SSC | CW [mm] | REL [mm] | RER [mm] | AN [deg] | CWTOLL [mm] |
| C2I-F2N-0250-0003-CR | ●○○○○ | ○●○ | ○ | ○○ | ● | ● | ○○ | ●F | 2.50 | 0.30 | 0.30 | 7.0 | -0.050 |
| ing C2I-G2N-0300-0003-CR | ●○○○○ | ○○●○ | ○ | ○○ | ● | ○● | ○○○ | ●G | 3.00 | 0.30 | 0.30 | 7.0 | -0.050 |
| ugh C2I-H2N-0400-0003-CR | ●○○○○ | ○○●○ | ○ | ○○ | ● | ○● | ○○○ | ●H | 4.00 | 0.30 | 0.30 | 7.0 | -0.050 |
| Ro C2I-J2N-0500-0004-CR | ●○○○○ | ○●○ | ○ | ○○ | ● | ● | ○○ | ●J | 5.00 | 0.40 | 0.40 | 7.0 | -0.050 |
| C2I-K2N-0600-0004-CR | ●○○○○ | ○●○ | ○ | ○○ | ● | ● | ○○ | ●K | 6.00 | 0.40 | 0.40 | 7.0 | -0.050 |
- = First choice ○ = Good choice
