CoroCut® 2, insert for parting
Right-hand version
CDX AN
REL CW RER
LIG
PSIRR
Metric (mm)
| P | M | K | N | S | |||||||||
| Ordering code | 1225 1135 3115 1145 | 4425 1225 1135 1145 | 1225 1135 3115 | 4425 1225 | 1225 | 1135 | 1145 SSC | CW [mm] | REL [mm] | RER [mm] | PSIRR [deg] | AN [deg] | CWTOLL [mm] |
| C2I-E2R-0200-0502-CM | ●○ ○ | ○●○ | ●○ | ● | ○ | ○ | ●E | 2.00 | 0.20 | 0.20 | 5.0 | 7.0 | -0.040 |
| m C2I-F2R-0250-0502-CM | ●○ ○ | ○●○ | ●○ | ● | ○ | ○ | ●F | 2.50 | 0.20 | 0.20 | 5.0 | 7.0 | -0.040 |
| ediu C2I-G2R-0300-0502-CM | ●○○○○ | ○●○ | ●○○ | ○● | ○ | ○ | ●G | 3.00 | 0.20 | 0.20 | 5.0 | 7.0 | -0.040 |
| M C2I-H2R-0400-0502-CM | ●○ ○ | ○●○ | ●○ | ● | ○ | ○ | ●H | 4.00 | 0.20 | 0.20 | 5.0 | 7.0 | -0.045 |
| C2I-J2R-0500-0502-CM | ●○ | ○● | ●○ | ● | ● | ○ | J | 5.00 | 0.20 | 0.20 | 5.0 | 7.0 | -0.045 |
- = First choice ○ = Good choice
