Milling tools | CoroMill® Plura CoroMill® Plura, solid carbide end mill for heavy duty milling​​ ISO-M - 4 flutes DCON KCH CHW LF DN LU/LB1 APMX DC Common data values ZEFP KCH FHA TCDCON TCDC [deg] [deg] 4 45.0 38.00 h6 h10 Metric (mm) M S M2CM M2CM Ordering code DC APMX CHW LU LF DCONMS [mm] [mm] [mm] [mm] [mm] [mm] 2P342-0600-MB ● ○ 6.00 13.0 0.1 13.00 57.00 6.00 2P342-0800-MB ● ○ 8.00 18.0 0.1 18.00 63.00 8.00 2P342-1000-MB ● ○ 10.00 22.0 0.2 22.00 72.00 10.00 2P342-1200-MB ● ○ 12.00 26.0 0.2 26.00 83.00 12.00 2P342-1600-MB ● ○ 16.00 34.0 0.3 42.00 97.00 16.00 ● = First choice ○ = Good choice 63
