Milling tools | CoroMill® Plura CoroMill® Plura, solid carbide ball nose end mill for profiling​​ For steel and hardened steel with hardness ≤ 63 HRc Common data values ZEFP FHA [deg] 2 30.00 Metric (mm) P M K S H 1610 1620 1620 1620 1620 1610 Ordering code DC RE APMX LU LF DCONMS DN BD 1 _ LB 1 _ LB 2 _ [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] R216.42-01030-AI10G ○ ● ● ○ ○ ● 1.00 0.5 1.0 1.00 57.00 6.00 1.0 17.5 20.7 R216.42-01530-AI15G ○ ● 1.50 0.8 1.5 2.00 57.00 6.00 1.5 17.9 20.0 R216.42-02030-AI20G ○ ● ● ○ ○ ● 2.00 1.0 2.0 2.00 57.00 6.00 2.0 18.3 20.5 R216.42-02530-AI25G ○ ● 2.50 1.3 2.5 2.50 57.00 6.00 2.5 18.8 20.0 R216.42-03030-AI03G ○ ● ● ○ ○ ● 3.00 1.5 3.0 3.00 57.00 6.00 3.0 19.1 20.5 R216.42-04030-AI04G ○ ● ● ○ ○ ● 4.00 2.0 4.0 4.00 57.00 6.00 2.5 20.0 22.3 R216.42-05030-AI05G ○ ● ● ○ ○ ● 5.00 2.5 5.0 20.00 57.00 6.00 4.9 4.9 20.0 21.1 R216.42-06030-AI06G ○ ● ● ○ ○ ● 6.00 3.0 6.0 21.00 57.00 6.00 5.7 R216.42-08030-AI08G ○ ● ● ○ ○ ● 8.00 4.0 8.0 27.00 63.00 8.00 7.7 R216.42-10030-AI10G ○ ● ● ○ ○ ● 10.00 5.0 10.0 32.00 72.00 10.00 9.7 R216.42-12030-AI12G ○ ● ● ○ ○ ● 12.00 6.0 12.0 36.00 83.00 12.00 11.4 ● = First choice ○ = Good choice 198
