Tapping tools | CoroTap® 100 CoroTap® 100, cutting tap with straight flutes​​ Thread form: UNC THL Common data values SUBSTRATE COATING HSS-E-PM PVD TiN Metric (mm) P P1PL Ordering code TDZ TD DCONMS TPI LU TCTR LF THL NOF PHD BSG THCHT [mm] [mm] [mm] [mm] [mm] [mm] T100-PM106AE-1/4 ● UNC 1/4-20 6.35 6.48 20 25.00 2BX 80.00 16.00 3 5.10 DIN/ANSI E = 1.5-2xTP T100-PM104AE-5/16 ● UNC 5/16-18 7.94 8.08 18 34.00 2BX 90.00 19.00 3 6.70 DIN/ANSI C = 2-3xTP T100-PM106AE-5/16 ● UNC 5/16-18 7.94 8.08 18 34.00 2BX 90.00 19.00 3 6.70 DIN/ANSI E = 1.5-2xTP T100-PM104AE-3/8 ● UNC 3/8-16 9.52 9.68 16 39.00 2BX 100.00 21.30 3 8.00 DIN/ANSI C = 2-3xTP T100-PM106AE-3/8 ● UNC 3/8-16 9.52 9.68 16 39.00 2BX 100.00 21.30 3 8.00 DIN/ANSI E = 1.5-2xTP T100-PM105AE-7/16 ● UNC 7/16-14 11.11 8.20 14 48.00 2BX 100.00 20.10 3 9.40 DIN/ANSI C = 2-3xTP T100-PM107AE-7/16 ● UNC 7/16-14 11.11 8.20 14 48.00 2BX 100.00 20.10 3 9.40 DIN/ANSI E = 1.5-2xTP T100-PM105AE-1/2 ● UNC 1/2-13 12.70 9.32 13 55.00 2BX 110.00 23.10 3 10.80 DIN/ANSI C = 2-3xTP T100-PM107AE-1/2 ● UNC 1/2-13 12.70 9.32 13 55.00 2BX 110.00 23.10 3 10.80 DIN/ANSI E = 1.5-2xTP T100-PM105AE-5/8 ● UNC 5/8-11 15.88 12.19 11 55.00 2BX 110.00 23.10 3 13.60 DIN/ANSI C = 2-3xTP T100-PM107AE-5/8 ● UNC 5/8-11 15.88 12.19 11 55.00 2BX 110.00 23.10 3 13.60 DIN/ANSI E = 1.5-2xTP ● = First choice ○ = Good choice 450
