Tapping tools | CoroTap® 100 CoroTap® 100, cutting tap with straight flutes​​ Thread form: Metric THL Common data values SUBSTRATE COATING HSS-E-PM PVD TiN Metric (mm) P P1PL Ordering code TDZ TP TD DCONMS LU TCTR LF THL NOF PHD BSG THCHT [mm] [mm] [mm] [mm] [mm] [mm] [mm] T100-PM175JA-M10 ● M 10 1.50 10.00 7.00 37.50 6HX 150.00 20.00 3 8.50 JIS-B-4430 C = 2-3xTP T100-PM175JA-M12 ● M 12 1.75 12.00 8.50 41.00 6HX 150.00 23.00 3 10.30 JIS-B-4430 C = 2-3xTP ● = First choice ○ = Good choice Thread form: Metric THL Common data values SUBSTRATE COATING HSS-E-PM PVD TiN Metric (mm) P P1PL Ordering code TDZ TP TD DCONMS LU TCTR LF THL NOF PHD BSG THCHT [mm] [mm] [mm] [mm] [mm] [mm] [mm] T100-PM104AA-M8 ● M 8 1.25 8.00 8.08 33.50 6HX 90.00 18.00 3 6.80 DIN/ANSI C = 2-3xTP T100-PM104AA-M10 ● M 10 1.50 10.00 9.68 38.50 6HX 100.00 20.00 3 8.50 DIN/ANSI C = 2-3xTP T100-PM105AA-M12 ● M 12 1.75 12.00 9.32 55.00 6HX 110.00 23.00 3 10.30 DIN/ANSI C = 2-3xTP T100-PM105AA-M16 ● M 16 2.00 16.00 12.19 55.00 6HX 110.00 25.00 3 14.50 DIN/ANSI C = 2-3xTP ● = First choice ○ = Good choice 445
