Milling tools | CoroMill® Dura CoroMill® Dura, solid carbide end mill for general machining​​ Optimised for non-ferrous materials, ISO N DCON DCON BS BS LF LF BHTA2 APMX/LU LB1 LB2 APMX/LU DC DC Common data values ZEFP FHA TCDC [deg] 3 35.00 h10 Metric (mm) N H10F Ordering code DC APMX LU DCONMS LF BS BD 1 LB 1 LB 2 TCDCON _ _ _ [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] 1K223-0200-NA ● 2.00 3.0 3.00 6.00 50.00 0.0 2.0 7.0 10.5 h6 1K223-0300-NA ● 3.00 4.5 4.50 6.00 50.00 0.0 3.0 9.6 12.2 h6 1K223-0400-NA ● 4.00 6.0 6.00 6.00 54.00 0.2 4.0 12.4 14.1 h6 1K223-0500-NA ● 5.00 7.5 7.50 6.00 54.00 0.3 5.0 14.5 15.4 h6 1K223-0600-NB ● 6.00 9.0 9.00 6.00 54.00 0.3 h6 1K223-0800-NB ● 8.00 12.0 12.00 8.00 58.00 0.3 h6 1K223-1000-NB ● 10.00 15.0 15.00 10.00 72.00 0.3 h6 1K223-1200-NB ● 12.00 18.0 18.00 12.00 83.00 0.4 h6 1K223-1600-NB ● 16.00 24.0 24.00 16.00 92.00 0.6 h6 1K223-2000-NB ● 20.00 30.0 30.00 20.00 104.00 0.7 h6 1K223-2500-NB ● 25.00 37.5 37.50 25.00 121.00 0.9 h6 ● = First choice ○ = Good choice 34
