Milling tools | CoroMill® Plura CoroMill® Plura, solid carbide end mill for stable multi-operations milling​​ For stainless steel and steel with hardness ≤ 48 HRc Common data values TCDCON TCDC h6 h9 Metric (mm) P M K S 1620 1620 1620 1620 Ordering code DC RE ZEFP APMX LU LF DCONMS DN FHA [mm] [mm] [mm] [mm] [mm] [mm] [mm] [deg] R216.24-20050GCC44P ● ● ○ ○ 20.00 3.0 4 44.0 80.00 130.00 20.00 19.0 48.29 R216.24-20050ICC38P ● ● ○ ○ 20.00 4.0 4 38.0 52.00 104.00 20.00 19.0 48.29 R216.24-20050ICC44P ● ● ○ ○ 20.00 4.0 4 44.0 80.00 130.00 20.00 19.0 48.29 R216.24-20050OCC44P ● ● ○ ○ 20.00 6.3 4 44.0 52.00 104.00 20.00 19.0 48.29 ● = First choice ○ = Good choice 116
