Milling tools | CoroMill® Plura CoroMill® Plura ball nose, solid carbide end mill for profiling​​ Optimised for heat resistant super alloys (HRSA) DCON DCON RE LF LF RE BHTA2 LB1 LB2 APMX/LU APMX/LU DC DC Common data values FHA TCDCON TCDC [deg] 30.000 h6 h10 Imperial (inch) K S H R2AH R2AH R2AH Ordering code DC RE ZEFP APMX LU LF DCONMS BD 1 LB 1 _ _ LB 2 _ [inch] [inch] [inch] [inch] [inch] [inch] [inch] [inch] [inch] 2B285-0318-RA ○ ● ○ 0.125 0.063 5 0.188 0.188 3.000 0.250 0.127 0.625 0.742 2B286-0476-RA ○ ● ○ 0.188 0.094 6 0.281 0.281 3.000 0.250 0.189 1.000 1.063 2B286-0635-RA ○ ● ○ 0.250 0.125 6 0.375 0.375 3.000 0.250 2B286-0794-RA ○ ● ○ 0.313 0.156 6 0.469 0.469 3.500 0.313 2B286-0953-RA ○ ● ○ 0.375 0.188 6 0.563 0.563 4.000 0.375 2B286-1270-RA ○ ● ○ 0.500 0.250 6 0.750 0.750 4.500 0.500 2B286-1588-RA ○ ● ○ 0.625 0.313 6 0.938 0.938 5.000 0.625 2B286-1905-RA ○ ● ○ 0.750 0.375 6 1.125 1.125 5.500 0.750 ● = First choice ○ = Good choice 171
