face milling
Bore with keyway - Internal coolant supply
Imperial (inch)
| Ordering code | DC [inch] | CNSC DCONMS [inch] | DHUB [inch] | BD [inch] | LB [inch] | LF [inch] | CDX [inch] | THUB [inch] | TQ [ft] RPMX [1/min] |
| L331.52C-080T25FM | 3.150 | 1 1.000 | 1.535 | 3.051 | 0.453 | 0.551 | 0.768 | 0.630 | 1.0 18100 |
| L331.52C-101T32FM | 4.000 | 1 1.250 | 1.811 | 3.874 | 0.453 | 0.551 | 1.043 | 0.630 | 1.0 15900 |
| L331.52C-127T38FM | 5.000 | 1 1.500 | 2.047 | 4.850 | 0.453 | 0.551 | 1.437 | 0.630 | 1.0 14100 |
| L331.52C-127T38KM | 5.000 | 1 1.500 | 2.047 | 4.854 | 0.567 | 0.659 | 1.437 | 0.728 | 2.2 12400 |
| L331.52C-152T38FM | 6.000 | 1 1.500 | 2.047 | 5.839 | 0.453 | 0.551 | 1.929 | 0.728 | 1.0 12400 |
| L331.52C-152T38KM | 6.000 | 1 1.500 | 2.047 | 5.831 | 0.567 | 0.659 | 1.929 | 0.728 | 2.2 10800 |
| R331.52C-080T25FM | 3.150 | 1 1.000 | 1.535 | 3.055 | 0.453 | 0.551 | 0.768 | 0.630 | 1.0 18100 |
| R331.52C-101T32FM | 4.000 | 1 1.250 | 1.811 | 3.874 | 0.453 | 0.551 | 1.043 | 0.630 | 1.0 15900 |
| R331.52C-127T38FM | 5.000 | 1 1.500 | 2.047 | 4.850 | 0.453 | 0.551 | 1.437 | 0.630 | 1.0 14100 |
| R331.52C-127T38KM | 5.000 | 1 1.500 | 2.047 | 4.854 | 0.567 | 0.659 | 1.437 | 0.728 | 2.2 12400 |
| R331.52C-152T38FM | 6.000 | 1 1.500 | 2.047 | 5.839 | 0.453 | 0.551 | 1.929 | 0.728 | 1.0 12400 |
| R331.52C-152T38KM | 6.000 | 1 1.500 | 2.047 | 5.831 | 0.567 | 0.659 | 1.929 | 0.728 | 2.2 10800 |
R = Right hand, L = Left hand
