face milling
Arbor shank - External coolant supply
Metric (mm)
| Ordering code DC [mm] | DCONMS [mm] | DHUB [mm] | LF [mm] | CDX [mm] | CW [mm] | TQ [Nm] | RPMX [1/min] | STDLET | DBC [mm] |
| R331.32-200Q40CM06.00 200.00 | 40.00 | 96.00 | 63.00 | 51.0 | 6.00 | 0.8 | 11700 | C | 66.7 |
| R331.32-200Q40DM08.00 200.00 | 40.00 | 96.00 | 63.10 | 51.0 | 8.00 | 1.2 | 9100 | C | 66.7 |
| R331.32-200Q40EM10.00 200.00 | 40.00 | 96.00 | 63.00 | 51.0 | 10.00 | 1.2 | 11000 | C | 66.7 |
| R331.32-200Q40FM12.00 200.00 | 40.00 | 96.00 | 63.00 | 51.0 | 12.00 | 1.2 | 11000 | C | 66.7 |
| R331.32-200Q40KM15.00 200.00 | 40.00 | 96.00 | 63.00 | 51.0 | 15.00 | 3.0 | 9600 | C | 66.7 |
| R331.32-200Q40LM17.50 200.00 | 40.00 | 96.00 | 63.00 | 51.0 | 17.50 | 3.0 | 9600 | C | 66.7 |
| R331.32-200Q40QM20.50 200.00 | 40.00 | 96.00 | 63.00 | 51.0 | 20.50 | 3.0 | 8000 | C | 66.7 |
| R331.32-200Q40RM23.50 200.00 | 40.00 | 96.00 | 63.00 | 51.0 | 23.50 | 3.0 | 8000 | C | 66.7 |
| R331.32-250Q60KM15.00 250.00 | 60.00 | 136.00 | 63.00 | 56.0 | 15.00 | 3.0 | 8500 | C | 101.6 |
| R331.32-250Q60LM17.50 250.00 | 60.00 | 136.00 | 63.00 | 56.0 | 17.50 | 3.0 | 8500 | C | 101.6 |
| R331.32-250Q60QM20.50 250.00 | 60.00 | 136.00 | 63.00 | 56.0 | 20.50 | 3.0 | 7100 | C | 101.6 |
| R331.32-250Q60RM23.50 250.00 | 60.00 | 136.00 | 63.00 | 56.0 | 23.50 | 3.0 | 7100 | C | 101.6 |
| R331.32-315Q60KM15.00 315.00 | 60.00 | 136.00 | 63.00 | 88.5 | 15.00 | 3.0 | 7600 | C | 101.6 |
| R331.32-315Q60LM17.50 315.00 | 60.00 | 136.00 | 63.00 | 88.5 | 17.50 | 3.0 | 7600 | C | 101.6 |
| R331.32-315Q60QM20.50 315.00 | 60.00 | 136.00 | 63.00 | 88.5 | 20.50 | 3.0 | 6300 | C | 101.6 |
| R331.32-315Q60RM23.50 315.00 | 60.00 | 136.00 | 63.00 | 88.5 | 23.50 | 3.0 | 6300 | C | 101.6 |
R = Right hand, L = Left hand
