Face milling tools | CoroMill® 345 CoroMill® 345, insert for milling Metric (mm) P H K M 4340 4330 4220 1010 1230 4220 1010 4340 4330 4220 1010 4340 1230 Ordering code SSC S BS RE IC LE BSR APMX KRINS HAND 530 530 530 [mm] [mm] [mm] [mm] [mm] [mm] [mm] [deg] 345R-1305E-PL ○ ○ ● ○ ○ ○ ● ○ ○ ○ ○ ○ ○ 13 5.05 2.0 0.8 13.00 8.8 107.0 6.0 45.00 Right Light PL 345R-1305M-PL ○ ● ○ ○ ○ ○ ● ○ ○ ○ ○ ○ ○ 13 5.05 2.0 0.8 13.00 8.8 107.0 6.0 45.00 Right ● = First choice ○ = Good choice 133
