CoroMill® 327, solid carbide head for thread milling
For internal threads. Whitworth 55° full form
Common data values
RPMX [1/min] Metric (mm) 80000
| P | S | K | M | N | |||||||||||||
| Ordering code | 1025 | 1025 | 1025 | 1025 | 1025 | DC1 [mm] | DCONMS [mm] | LF1 [mm] | LF2 [mm] | LB [mm] | BD [mm] | OAL [mm] | TPI | ZEFP | APMX [mm] | KAPR [deg] | |
| 327R06-12 11WH-TH | ○ | ○ | ○ | ○ | ○ | 11.70 | 6.00 | 2.00 | 3.60 | 2.0 | 8.7 | 3.60 | 11 | 3 | 1.5 | 27.5 | |
| 327R06-12 14WH-TH | ○ | ○ | ○ | ○ | ○ | 11.70 | 6.00 | 2.30 | 3.60 | 2.3 | 9.4 | 3.60 | 14 | 3 | 1.2 | 27.5 | |
| 327R06-12 19WH-TH | ○ | ○ | ○ | ○ | ○ | 11.70 | 6.00 | 2.45 | 3.60 | 2.5 | 10.0 | 3.60 | 19 | 3 | 0.9 | 27.5 | |
| 327R09-18 11WH-TH | ○ | ○ | ○ | ○ | ○ | 17.70 | 9.00 | 4.40 | 5.85 | 4.4 | 14.7 | 5.85 | 11 | 3 | 1.5 | 27.5 | |
| 327R09-18 14WH-TH | ○ | ○ | ○ | ○ | ○ | 17.70 | 9.00 | 4.65 | 5.85 | 4.7 | 15.4 | 5.85 | 14 | 3 | 1.2 | 27.5 | |
| 327R09-18 19WH-TH | ○ | ○ | ○ | ○ | ○ | 17.70 | 9.00 | 4.85 | 5.85 | 4.8 | 16.0 | 5.85 | 19 | 3 | 0.9 | 27.5 |
- = First choice = Good choice
