CoroMill® 331, insert for side and face milling
Cutter bodies for radii inserts available as Tailor Made
Metric (mm)
| P | S | M | ||||||||||||||||
| Ordering code | 1040 | 2040 | S30T | 1040 | 2040 | S30T | 1040 | 2040 | SSC | S [mm] | BS [mm] | RE [mm] | W1 [mm] | LE [mm] | APMX [mm] | KRINS [deg] | HAND | |
| L331.1A-115030E-L50 | ○ | ○ | ● | ○ | ○ | ○ | ● | ○ | 11 | 5.00 | 1.3 | 3.0 | 11.5 | 10.7 | 10.7 | 90.00 | Left | |
| L331.1A-115040E-L50 | ○ | ○ | ● | ○ | ○ | ○ | ● | ○ | 11 | 5.00 | 1.4 | 4.0 | 11.5 | 10.7 | 10.7 | 90.00 | Left | |
| L331.1A-115048E-L50 | ○ | ○ | ● | ○ | ○ | ○ | ● | ○ | 11 | 5.00 | 1.5 | 4.8 | 11.5 | 10.7 | 10.7 | 90.00 | Left | |
| ght 50 | L331.1A-115063E-L50 | ○ | ○ | ● | ○ | ○ | ○ | ● | ○ | 11 | 5.00 | 1.6 | 6.3 | 11.5 | 10.7 | 10.7 | 90.00 | Left |
| Li L | R331.1A-115030E-L50 | ○ | ○ | ● | ○ | ○ | ○ | ● | ○ | 11 | 5.00 | 1.3 | 3.0 | 11.5 | 10.7 | 10.7 | 90.00 | Right |
| R331.1A-115040E-L50 | ○ | ○ | ● | ○ | ○ | ○ | ● | ○ | 11 | 5.00 | 1.4 | 4.0 | 11.5 | 10.7 | 10.7 | 90.00 | Right | |
| R331.1A-115048E-L50 | ○ | ○ | ● | ○ | ○ | ○ | ● | ○ | 11 | 5.00 | 1.5 | 4.8 | 11.5 | 10.7 | 10.7 | 90.00 | Right | |
| R331.1A-115063E-L50 | ○ | ○ | ● | ○ | ○ | ○ | ● | ○ | 11 | 5.00 | 1.6 | 6.3 | 11.5 | 10.7 | 10.7 | 90.00 | Right |
