CoroMill® 331, insert for side and face milling
Cutter bodies for radii inserts available as Tailor Made
Metric (mm)
| P | H | K | M | ||||||||||||||||
| Ordering code | 4330 | 1230 | 3040 | 3040 | 4330 | 1020 | 3040 | 1230 | SSC | S [mm] | BS [mm] | RE [mm] | W1 [mm] | LE [mm] | APMX [mm] | KRINS [deg] | HAND | ||
| L331.1A-08 45 40H-WM | ○ | ● | ○ | ○ | ○ | ● | ○ | ○ | 08 | 4.45 | 1.4 | 4.0 | 9.5 | 7.7 | 7.7 | 90.00 | Left | ||
| L331.1A-11 50 40H-WM | ○ | ● | ○ | ○ | ○ | ● | ○ | ○ | 11 | 4.95 | 1.4 | 4.0 | 11.5 | 10.7 | 10.7 | 90.00 | Left | ||
| ium M | L331.1A-14 50 40H-WM | ○ | ● | ○ | ○ | ○ | ● | ○ | ○ | 14 | 4.95 | 1.4 | 4.0 | 11.5 | 13.7 | 13.7 | 90.00 | Left | |
| Med W | R331.1A-08 45 40H-WM | ○ | ● | ○ | ○ | ○ | ● | ○ | ○ | 08 | 4.45 | 1.4 | 4.0 | 9.5 | 7.7 | 7.7 | 90.00 | Right | |
| R331.1A-11 50 40H-WM | ○ | ● | ○ | ○ | ○ | ● | ○ | ○ | 11 | 4.95 | 1.4 | 4.0 | 11.5 | 10.7 | 10.7 | 90.00 | Right | ||
| R331.1A-14 50 40H-WM | ○ | ● | ○ | ○ | ○ | ● | ○ | ○ | 14 | 4.95 | 1.4 | 4.0 | 11.5 | 13.7 | 13.7 | 90.00 | Right |
