Profile milling tools | CoroMill® 200 CoroMill® 200, insert for milling Imperial (inch) P H M S30T S40T 4340 4220 4330 1010 1230 4220 1010 4340 1230 Ordering code SSC S RE IC APMX HAND [inch] [inch] [inch] [inch] RCKT 09 T3 00-PH ○○● ○● 3/8 0.156 0.188 0.375 0.188 Neutral Heavy RCKT 13 04 00-PH ○ ○ ● ○● PH 1/2 0.188 0.250 0.500 0.073 Neutral RCKT 19 06 00-PH ○ ○ ● ○● 3/4 0.250 0.375 0.750 0.110 Neutral RCHT 09 T3 00-PL ○● ● ○ 3/8 0.156 0.188 0.375 0.188 Neutral Light ○● ● ○ 1/2 0.188 0.250 0.500 0.073 Neutral PL RCHT 13 04 00-PL RCHT 19 06 00-PL ● ○ 3/4 0.250 0.375 0.750 0.110 Neutral RCKT 09 T3 00-PM ● ○ ○ 3/8 0.156 0.188 0.375 0.188 Neutral Medium RCKT 13 04 00-PM ○ ○ ● ○ ● ○ ○ ○ ○ 1/2 0.188 0.250 0.500 0.073 Neutral PM RCKT 19 06 00-PM ○ ● ○ ○ ○ ○ ○ 3/4 0.250 0.375 0.750 0.110 Neutral ● = First choice ○ = Good choice 239
