High feed milling tools | CoroMill® 419 CoroMill® 419, insert for milling Metric (mm) P S K M S30T S40T S30T S40T 4340 4330 1230 1040 2040 1230 1040 2040 4340 4330 1020 4340 1230 1040 2040 Ordering code SSC S RE IC REEQ LE APMX KRINS [mm] [mm] [mm] [mm] [mm] [mm] [deg] 419N-140530E-SM ○ ● ○ ○ ○ ● ○ ○ ○ ○ ○ ○ ● ○ ○ ○ ○ ● ○ 14 5.47 3.0 13.50 4.5 9.0 2.0 19.00 Medium SM ● = First choice ○ = Good choice 200
