Shoulder milling tools | CoroMill® 490 CoroMill® 490, insert for milling Advanced cutting materials Metric (mm) K 6190 Ordering code SSC S BS RE IC LE APMX KRINS HAND [mm] [mm] [mm] [mm] [mm] [mm] [deg] 490R-140408E ○ 14 3.90 0.8 0.8 13.80 5.0 5.0 90.00 Right Medium 490R-140420E ○ 14 PO 3.90 0.8 2.0 13.80 5.0 5.0 90.00 Right ● = First choice ○ = Good choice Advanced cutting materials Metric (mm) H K CB50 CB50 Ordering code SSC S BS RE IC LE APMX KRINS HAND [mm] [mm] [mm] [mm] [mm] [mm] [deg] 490R-140408E ○ ○ 14 3.90 1.5 0.8 13.80 2.0 2.0 90.00 Right Medium PO ● = First choice ○ = Good choice 102
