Плечевые фрезы | CoroMill® MS20
CoroMill® MS20 — державка резца для фрезерования
| Код заказа | Совместимость | SSC | S [мм] | BS [мм] | RE [мм] | W1 [мм] | LE [мм] | APMX [мм] | KRINS [°] | HAND |
|---|---|---|---|---|---|---|---|---|---|---|
| MS20-10T304E-L50 | Легкие | 10 | 3.60 | 1.2 | 0.4 | 6.7 | 9.1 | 9.0 | 90.00 | Right |
| MS20-10T308E-L50 | Легкие | 10 | 3.60 | 1.2 | 0.8 | 6.7 | 9.1 | 9.0 | 90.00 | Right |
| MS20-10T316E-L50 | Легкие | 10 | 3.60 | 1.2 | 1.6 | 6.7 | 9.1 | 9.0 | 90.00 | Right |
| MS20-10T324E-L50 | Легкие | 10 | 3.60 | 1.0 | 2.4 | 6.7 | 9.1 | 9.0 | 90.00 | Right |
| MS20-10T331E-L50 | Легкие | 10 | 3.60 | 0.2 | 3.1 | 6.7 | 9.1 | 9.0 | 90.00 | Right |
● = Первый выбор ○ = Хороший выбор
