CoroMill® Century, insert for milling
Wiper technology
Metric (mm)
H K
Ordering code SSC S BS KCH CHW W1 LE BSR APMX KRINS HAND
[mm] [mm] [deg] [mm] [mm] [mm] [mm] [mm] [deg]
| L590-1105H-ZC2-KW | 11 | 5.00 5.9 | 60.0 1.5 | 11.5 3.0 | 390.0 1.2 | 90.00 Left |
| R590-1105H-ZC2-KW | 11 | 5.00 5.9 | 60.0 1.5 | 11.5 3.0 | 390.0 1.2 | 90.00 Right |
- = First choice = Good choice
Wiper technology
Metric (mm)
H K
Ordering code SSC S BS RE W1 LE BSR APMX KRINS HAND
[mm] [mm] [mm] [mm] [mm] [mm] [mm] [deg]
R590-110508H-PR2-KW 11 5.00 7.1 0.8 11.5 2.0 393.0 2.0 90.00 Right
- = First choice = Good choice
