Face milling tools | CoroMill® 245 CoroMill® 245, insert for milling Metric (mm) P S H K N K20W H13A H13A H13A 3040 3040 1220 1020 3220 3330 3040 Ordering code SSC S BS RE IC LE APMX KRINS HAND [mm] [mm] [mm] [mm] [mm] [mm] [deg] ○ ○ ○○●○○ Heavy R245-12 T3 M-KH 12 3.97 2.0 1.5 13.40 10.0 6.5 45.00 Right KH R245-12 T3 M-KM ○ ○ ○ ○ ○ ○ ○ ● ○ ○ ● 12 3.97 2.0 1.5 13.40 10.0 6.5 45.00 Right Medium ○ ○ ○ ○ ● ○ ○ 18 KM R245-18 T6 M-KM 6.10 1.5 1.0 18.00 13.9 9.8 45.00 Right ● = First choice ○ = Good choice 118
