Инструменты для сверления | CoroDrill® 860
CoroDrill® 860-MM, сверло из цельного твердого сплава для ISO-M
Номинальная глубина сверления 3xD. Внутренняя подача СОЖ.
Общие значения данных
Покрытие: PVD TiAlSiN
Метрическая (мм), группа материалов: M, обозначение: M2BM
| Код заказа | M | DC [мм] | LU [мм] | LCF [мм] | OAL [мм] | DCONMS [мм] | SIG [град] | LF [мм] | PL [мм] | ULDR | CP [бар] | TCDCON | TCHA |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 860.1-1020-040A1-MM | ● | 10.20 | 40.00 | 55.00 | 102.00 | 12.00 | 140.00 | 100.14 | 1.86 | 3.92 | 20 | h6 | H9 |
| 860.1-1030-040A1-MM | ● | 10.30 | 40.00 | 55.00 | 102.00 | 12.00 | 140.00 | 100.13 | 1.87 | 3.88 | 20 | h6 | H9 |
| 860.1-1032-040A1-MM | ● | 10.32 | 40.00 | 55.00 | 102.00 | 12.00 | 140.00 | 100.12 | 1.88 | 3.88 | 20 | h6 | H9 |
| 860.1-1040-040A1-MM | ● | 10.40 | 40.00 | 55.00 | 102.00 | 12.00 | 140.00 | 100.11 | 1.89 | 3.85 | 20 | h6 | H9 |
| 860.1-1050-040A1-MM | ● | 10.50 | 40.00 | 55.00 | 102.00 | 12.00 | 140.00 | 100.09 | 1.91 | 3.81 | 20 | h6 | H9 |
| 860.1-1060-040A1-MM | ● | 10.60 | 40.00 | 55.00 | 102.00 | 12.00 | 140.00 | 100.07 | 1.93 | 3.77 | 20 | h6 | H9 |
| 860.1-1070-040A1-MM | ● | 10.70 | 40.00 | 55.00 | 102.00 | 12.00 | 140.00 | 100.05 | 1.95 | 3.74 | 20 | h6 | H9 |
| 860.1-1072-040A1-MM | ● | 10.72 | 40.00 | 55.00 | 102.00 | 12.00 | 140.00 | 100.05 | 1.95 | 3.73 | 20 | h6 | H9 |
| 860.1-1080-040A1-MM | ● | 10.80 | 40.00 | 55.00 | 102.00 | 12.00 | 140.00 | 100.04 | 1.97 | 3.70 | 20 | h6 | H9 |
| 860.1-1090-040A1-MM | ● | 10.90 | 40.00 | 55.00 | 102.00 | 12.00 | 140.00 | 100.02 | 1.98 | 3.67 | 20 | h6 | H9 |
| 860.1-1100-040A1-MM | ● | 11.00 | 40.00 | 55.00 | 102.00 | 12.00 | 140.00 | 100.00 | 2.00 | 3.64 | 20 | h6 | H9 |
| 860.1-1110-040A1-MM | ● | 11.10 | 40.00 | 55.00 | 102.00 | 12.00 | 140.00 | 99.98 | 2.02 | 3.60 | 20 | h6 | H9 |
| 860.1-1111-040A1-MM | ● | 11.11 | 40.00 | 55.00 | 102.00 | 12.00 | 140.00 | 99.98 | 2.02 | 3.60 | 20 | h6 | H9 |
| 860.1-1120-040A1-MM | ● | 11.20 | 40.00 | 55.00 | 102.00 | 12.00 | 140.00 | 99.96 | 2.04 | 3.57 | 20 | h6 | H9 |
| 860.1-1130-040A1-MM | ● | 11.30 | 40.00 | 55.00 | 102.00 | 12.00 | 140.00 | 99.94 | 2.06 | 3.54 | 20 | h6 | H9 |
| 860.1-1140-040A1-MM | ● | 11.40 | 40.00 | 55.00 | 102.00 | 12.00 | 140.00 | 99.93 | 2.08 | 3.51 | 20 | h6 | H9 |
| 860.1-1150-040A1-MM | ● | 11.50 | 40.00 | 55.00 | 102.00 | 12.00 | 140.00 | 99.91 | 2.09 | 3.48 | 20 | h6 | H9 |
| 860.1-1151-040A1-MM | ● | 11.51 | 40.00 | 55.00 | 102.00 | 12.00 | 140.00 | 99.90 | 2.10 | 3.48 | 20 | h6 | H9 |
| 860.1-1160-040A1-MM | ● | 11.60 | 40.00 | 55.00 | 102.00 | 12.00 | 140.00 | 99.89 | 2.11 | 3.45 | 20 | h6 | H9 |
| 860.1-1170-040A1-MM | ● | 11.70 | 40.00 | 55.00 | 102.00 | 12.00 | 140.00 | 99.87 | 2.13 | 3.42 | 20 | h6 | H9 |
| 860.1-1180-040A1-MM | ● | 11.80 | 40.00 | 55.00 | 102.00 | 12.00 | 140.00 | 99.85 | 2.15 | 3.39 | 20 | h6 | H9 |
| 860.1-1190-040A1-MM | ● | 11.90 | 40.00 | 55.00 | 102.00 | 12.00 | 140.00 | 99.83 | 2.17 | 3.36 | 20 | h6 | H9 |
| 860.1-1210-043A1-MM | ● | 12.10 | 43.00 | 60.00 | 107.00 | 14.00 | 140.00 | 104.80 | 2.20 | 3.55 | 20 | h6 | H9 |
| 860.1-1220-043A1-MM | ● | 12.20 | 43.00 | 60.00 | 107.00 | 14.00 | 140.00 | 104.78 | 2.22 | 3.52 | 20 | h6 | H9 |
| 860.1-1230-043A1-MM | ● | 12.30 | 43.00 | 60.00 | 107.00 | 14.00 | 140.00 | 104.76 | 2.24 | 3.50 | 20 | h6 | H9 |
| 860.1-1250-043A1-MM | ● | 12.50 | 43.00 | 60.00 | 107.00 | 14.00 | 140.00 | 104.72 | 2.28 | 3.44 | 20 | h6 | H9 |
| 860.1-1260-043A1-MM | ● | 12.60 | 43.00 | 60.00 | 107.00 | 14.00 | 140.00 | 104.71 | 2.29 | 3.41 | 20 | h6 | H9 |
| 860.1-1270-043A1-MM | ● | 12.70 | 43.00 | 60.00 | 107.00 | 14.00 | 140.00 | 104.69 | 2.31 | 3.39 | 20 | h6 | H9 |
| 860.1-1280-043A1-MM | ● | 12.80 | 43.00 | 60.00 | 107.00 | 14.00 | 140.00 | 104.67 | 2.33 | 3.36 | 20 | h6 | H9 |
| 860.1-1290-043A1-MM | ● | 12.90 | 43.00 | 60.00 | 107.00 | 14.00 | 140.00 | 104.65 | 2.35 | 3.33 | 20 | h6 | H9 |
● — первый выбор, ○ — хороший выбор.
