Инструмент для фрезерования | CoroMill® Plura
CoroMill® Plura, концевая фреза из цельного твердого сплава для тяжелого фрезерования
ISO-P — 4 зуба.
| Общие значения | |||
|---|---|---|---|
| ZEFP: 4 | KCH [град]: 45.0 | TCDCON: h6 | TCDC: h10 |
| Код заказа | DC [мм] | APMX [мм] | CHW [мм] | LU [мм] | LF [мм] | DCONMS [мм] | BD1 [мм] | LB1 [мм] | LB2 [мм] | FHA [град] |
|---|---|---|---|---|---|---|---|---|---|---|
| 2P342-0200-PA ● | 2.00 | 5.0 | 0.1 | 5.00 | 57.00 | 6.00 | 2.0 | 10.5 | 14.0 | 38.00 |
| 2P342-0300-PA ● | 3.00 | 7.0 | 0.1 | 7.00 | 57.00 | 6.00 | 3.0 | 13.6 | 16.2 | 38.00 |
| 2P342-0400-PA ● | 4.00 | 9.0 | 0.1 | 9.00 | 57.00 | 6.00 | 4.1 | 15.0 | 16.7 | 38.00 |
| 2P342-0500-PA ● | 5.00 | 11.0 | 0.1 | 11.00 | 57.00 | 6.00 | 5.1 | 17.0 | 16.9 | 38.00 |
| 2P342-0600-PB ● | 6.00 | 13.0 | 0.1 | 13.00 | 57.00 | 6.00 | 38.00 | |||
| 2P342-0800-PB ● | 8.00 | 18.0 | 0.1 | 18.00 | 63.00 | 8.00 | 38.00 | |||
| 2P342-1000-PB ● | 10.00 | 22.0 | 0.2 | 22.00 | 72.00 | 10.00 | 42.00 | |||
| 2P342-1200-PB ● | 12.00 | 26.0 | 0.2 | 26.00 | 83.00 | 12.00 | 42.00 | |||
| 2P342-1400-PB ● | 14.00 | 30.0 | 0.2 | 30.00 | 90.00 | 14.00 | 42.00 | |||
| 2P342-1600-PB ● | 16.00 | 34.0 | 0.3 | 34.00 | 97.00 | 16.00 | 42.00 | |||
| 2P342-2000-PB ● | 20.00 | 42.0 | 0.3 | 42.00 | 109.60 | 20.00 | 42.00 | |||
| 2P342-2500-PB ● | 25.00 | 52.0 | 0.3 | 52.00 | 129.50 | 25.00 | 42.00 |
● = Первый выбор ○ = Хороший выбор
