Фрезерный инструмент | CoroMill® Plura
CoroMill® Plura, концевая фреза из твёрдого сплава для стабильного многофункционального фрезерования
Для нержавеющей стали и стали твёрдостью ≤ 48 HRc.
Общие значения параметров
| ZEFP | KCH [град] | TCDCON | TCDC |
|---|---|---|---|
| 4 | 45.0 | h6 | h10 |
Метрическая система (мм)
P 1620/1630/1640, M 1620/1630/1640, K 1620/1630/1640, S 1620/1630/1640
| Код заказа | DC [мм] | APMX [мм] | CHW [мм] | LU [мм] | LF [мм] | DCONMS [мм] | FHA [град] |
|---|---|---|---|---|---|---|---|
| R216.34-06050-BC13P ● ● ○ ● ● ● ○ ○ ○ ○ ○ ● | 6.00 | 13.0 | 0.1 | 13.00 | 57.00 | 6.00 | 49.67 |
| R216.34-08050-BC19P ● ● ○ ● ● ● ○ ○ ○ ○ ○ ● | 8.00 | 19.0 | 0.1 | 19.00 | 63.00 | 8.00 | 48.29 |
| R216.34-10050-BC22P ● ● ○ ● ● ● ○ ○ ○ ○ ○ ● | 10.00 | 22.0 | 0.1 | 22.00 | 72.00 | 10.00 | 48.29 |
| R216.34-12050-BC26P ● ● ○ ● ● ● ○ ○ ○ ○ ○ ● | 12.00 | 26.0 | 0.1 | 26.00 | 83.00 | 12.00 | 46.72 |
| R216.34-14050-BC26P ● ● ○ ● ● ● ○ ○ ○ ○ ○ ● | 14.00 | 26.0 | 0.2 | 26.00 | 83.00 | 14.00 | 47.72 |
| R216.34-16050-BC32P ● ● ○ ● ● ● ○ ○ ○ ○ ○ ● | 16.00 | 32.0 | 0.2 | 32.00 | 92.00 | 16.00 | 48.16 |
| R216.34-20050-BC38P ● ● ○ ● ● ● ○ ○ ○ ○ ○ ● | 20.00 | 38.0 | 0.2 | 38.00 | 104.00 | 20.00 | 48.29 |
● = Первый выбор ○ = Хороший выбор
