Инструменты для нарезания резьбы | CoroTap® 200
CoroTap® 200, машинный метчик со спиральной канавкой
Профиль резьбы: Метрическая мелкая
Общие параметры: ОСНОВА — HSS-E-PM, Покрытие — PVD TiAlN
Метрическая (мм): P, P1PM
| Код заказа | Выбор | Резьба | TP [мм] | TD [мм] | DCONMS [мм] | LU [мм] | TCTR | LF [мм] | THL [мм] | NOF | PHD [мм] | BSG | THCHT |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| T200-PM100AB-M8X100 | ● | MF 8x1 | 1.00 | 8.00 | 8.08 | 33.50 | 6HX | 90.00 | 18.00 | 3 | 7.00 | DIN/ANSI | B = 3.5-5xTP Gunnose |
| T200-PM100AB-M10X125 | ● | MF 10x1.25 | 1.25 | 10.00 | 9.68 | 38.00 | 6HX | 100.00 | 20.00 | 3 | 8.80 | DIN/ANSI | B = 3.5-5xTP Gunnose |
| T200-PM101AB-M12X125 | ● | MF 12x1.25 | 1.25 | 12.00 | 9.32 | 55.00 | 6HX | 110.00 | 23.00 | 3 | 10.80 | DIN/ANSI | B = 3.5-5xTP Gunnose |
| T200-PM101AB-M12X150 | ● | MF 12x1.5 | 1.50 | 12.00 | 9.32 | 55.00 | 6HX | 110.00 | 23.00 | 3 | 10.50 | DIN/ANSI | B = 3.5-5xTP Gunnose |
| T200-PM101AB-M14X150 | ● | MF 14x1.5 | 1.50 | 14.00 | 10.90 | 55.00 | 6HX | 110.00 | 23.00 | 3 | 12.50 | DIN/ANSI | B = 3.5-5xTP Gunnose |
| T200-PM101AB-M16X150 | ● | MF 16x1.5 | 1.50 | 16.00 | 12.19 | 55.00 | 6HX | 110.00 | 23.00 | 4 | 14.50 | DIN/ANSI | B = 3.5-5xTP Gunnose |
| T200-PM101AB-M18X150 | ● | MF 18x1.5 | 1.50 | 18.00 | 13.77 | 72.00 | 6HX | 125.00 | 30.00 | 4 | 16.50 | DIN/ANSI | B = 3.5-5xTP Gunnose |
● = Первый выбор ○ = Хороший выбор
