Запасные части
| Обозначение | Компоненты | |||
|---|---|---|---|---|
| C4 SIL-12060-16 | AE16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C4 SIR-12060-16 | T-10/5 | |||
| C4 SIL-14060-16 | AE16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C4 SIR-14060-16 | AI16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C4 SIR-15065-22 | T-20/5 | |||
| C4 SIL-17070-16 | AE16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C4 SIL-19070-22 | AE22 | SR 8-32-L5.8-A22 | SR 8-32-L15-S22 | T-20/5 |
| C4 SIR-17070-16 | AI16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C4 SIR-19070-22 | AI22 | SR 8-32-L5.8-A22 | SR 8-32-L15-S22 | T-20/5 |
| C4 SIL-22090-16 | AE16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C4 SIR-22090-16 | AI16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C4 SIL-22090-22 | AE22 | SR 8-32-L5.8-A22 | SR 8-32-L15-S22 | T-20/5 |
| C4 SIR-22090-22 | AI22 | SR 8-32-L5.8-A22 | SR 8-32-L15-S22 | T-20/5 |
| C4 SIL-27080-16 | AE16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C4 SIR-27080-16 | AI16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C4 SIL-27080-22 | AE22 | SR 8-32-L5.8-A22 | SR 8-32-L15-S22 | T-20/5 |
| C4 SIR-27080-22 | AI22 | SR 8-32-L5.8-A22 | SR 8-32-L15-S22 | T-20/5 |
| C5 SIR/L-12060-16 | T-10/5 | |||
| C5 SIL-14060-16 | AE16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C5 SIL-15065-22 | AE22 | SR 8-32-L5.8-A22 | SR 8-32-L15-S22 | T-20/5 |
| C5 SIR-14060-16 | AI16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C5 SIR-15065-22 | AI22 | SR 8-32-L5.8-A22 | SR 8-32-L15-S22 | T-20/5 |
| C5 SIL-17070-16 | AE16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C5 SIL-19070-22 | AE22 | SR 8-32-L5.8-A22 | SR 8-32-L15-S22 | T-20/5 |
| C5 SIR-17070-16 | AI16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C5 SIR-19070-22 | AI22 | SR 8-32-L5.8-A22 | SR 8-32-L15-S22 | T-20/5 |
| C5 SIL-22090-16 | AE16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C5 SIR-22090-16 | AI16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C5 SIL-22090-22 | AE22 | SR 8-32-L5.8-A22 | SR 8-32-L15-S22 | T-20/5 |
| C5 SIR-22090-22 | AI22 | SR 8-32-L5.8-A22 | SR 8-32-L15-S22 | T-20/5 |
| C5 SIL-27105-16 | AE16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C5 SIR-27105-16 | AI16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C5 SIL-27105-22 | AE22 | SR 8-32-L5.8-A22 | SR 8-32-L15-S22 | T-20/5 |
| C5 SIR-27105-22 | AI22 | SR 8-32-L5.8-A22 | SR 8-32-L15-S22 | T-20/5 |
| C6 SIL-14070-16 | AE16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C6 SIR-14070-16 | AI16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C6 SIL-17075-16 | AE16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C6 SIL-19075-22 | AE22 | SR 8-32-L5.8-A22 | SR 8-32-L15-S22 | T-20/5 |
| C6 SIR-17075-16 | AI16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C6 SIR-19075-22 | AI22 | SR 8-32-L5.8-A22 | SR 8-32-L15-S22 | T-20/5 |
| C6 SIL-22090-16 | AE16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C6 SIR-22090-16 | AI16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C6 SIL-22090-22 | AE22 | SR 8-32-L5.8-A22 | SR 8-32-L15-S22 | T-20/5 |
| C6 SIR-22090-22 | AI22 | SR 8-32-L5.8-A22 | SR 8-32-L15-S22 | T-20/5 |
| C6 SIL-27105-16 | AE16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C6 SIR-27105-16 | AI16 | SR 5-40-L6.8-A16 | SR 5-40-L12.2-S16 | T-10/5 |
| C6 SIL-27105-22 | AE22 | SR 8-32-L5.8-A22 | SR 8-32-L15-S22 | T-20/5 |
| C6 SIR-27105-22 | AI22 | SR 8-32-L5.8-A22 | SR 8-32-L15-S22 | T-20/5 |
