Материалы и сорта
Обозначение материалов в соответствии с выбранными стандартами
Номер группы материалов: 34
| Стандарт | Материал 1 | Материал 2 | Материал 3 | Материал 4 | Материал 5 | Материал 6 | Материал 7 | Материал 8 | Материал 9 | Материал 10 |
|---|---|---|---|---|---|---|---|---|---|---|
| NF/AFNOR (Франция) | Z 8 NCDT 42 | NCK 19 DAT | NC 20 TA | NC 20 K 14 | NC 19 KDT | NC 14 K8 | ||||
| AISI/ASM/ASTM/SAE/UNS/AA (США) | Incoloy 925; N09925 | Nimonic 901; N09901; AMS 5660; AMS 5661 | Udimet 500; N07500; AISI 684 | Nimonic 80A; N07080 | MAR-M 246 | Inconel 722; N07722; AMS 5411 | Waspaloy; N07001; AISI 685; AMS 5704; AMS 5706; AMS 5708; AMS 5544 | Rene 41; N07041; AMS 5712; AMS 5713; AMS 5800 | Rene 95 | |
| BS (Великобритания) | HR 401; HR 601 | |||||||||
| DIN (Германия) | NiFe35Cr14MoTi; NiCr13Mo6Ti3; NiCr 13 Mo 6 Ti 3 | NiCr18Co18MoAlTi | NiCr20TiAl; NiCr 20 TiAl | NiCr23Mo16Cu; NiCr 23 Mo 16 Cu | NiCr20Co13Mo4Ti3AL; NiCr 19 Co 14 Mo 4 Ti | NiCr19Co11MoTi; NiCr 19 CoMo | ||||
| Werkstoff (Германия) | 2.4662 | 2.4983 | 2.4631; 2.4952 | 2.4675 | 2.4654 | 2.4973 | ||||
| EN (Европа) | NiCr18Co18MoAlTi | NiCr20TiAl | NiCr23Mo16Cu | NiCr20Co13Mo4Ti3AL | ||||||
| GOST (Россия) | ChN77TYuR; ChN56VMTYu | ChN75VMYu; EI 827 | ||||||||
| JIS (Япония) | NCF 80 A | |||||||||
| SS (Швеция) | ||||||||||
| UNE (Испания) | ||||||||||
| UNI (Италия) | ||||||||||
| IS (Индия) | ||||||||||
| KS (Республика Корея) | ||||||||||
| GB/YB/JB/SY/NB (КНР) | GH80A | GH141 | GH738 |
