РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ
МАТЕРИАЛЫ И СОРТА
Обозначение материалов в соответствии с выбранными стандартами
Номер группы материалов 29, 31
| Стандарты | Обозначения материалов |
|---|---|
| NF/AFNOR (ФРАНЦИЯ) | Z 20 NCS 33-16; Z 12 NCS 37-18; Z 12 NCS 35-16 |
| AISI/ASM/ASTM/SAE/UNS/AA (США) | 330; N08330, N08002; N08004; N08005; N08030, N08031 |
| BS (ВЕЛИКОБРИТАНИЯ) | 330 C 11; 330 C 40; 331 C 40; NA 17, INCOLOY alloy DS, NA 15 |
| DIN (ГЕРМАНИЯ) | X12NiCrSi35-16; X12NiCrSi36-16; X12 NiCrSi 36 16, GX40NiCrSi38-19; GX40NiCrSi38-18; G-X40 NiCrSi38 18, X2NiCrAlTi32-20; X2 NiCrAITi 32 20, X1NiCrMoCu32-28-7; X1 NiCrMoCu 32 28 7 |
| Werkstoff (ГЕРМАНИЯ) | 1.486, 1.487, 1.456, 1.456 |
| EN (ЕВРОПА) | X12NiCrSi35-16, GX40NiCrSi38-18, X2NiCrAlTi32-20, X1NiCrMoCu32-28-7 |
| GOST (РОССИЯ) | Capron; Nylon, Polymetylmetakrylat; orgsteklo; SOL; ST-1; 2-55, PVCh, Polystyrol, Teflon; PTFE; Ftoroplast-4, RST; RST-250; RST-275; RST-320; RST-410 |
| JIS (ЯПОНИЯ) | SUH 330, SCH 15; SCH 16, NCF 800 |
| SS (ШВЕЦИЯ) | |
| UNE (ИСПАНИЯ) | F.3313; X 12 CrNiSi 36-16 |
| UNI (ИТАЛИЯ) | GX 50 NiCr 39 19 |
| IS (ИНДИЯ) | |
| KS (РЕСПУБЛИКА КОРЕЯ) | STR 330, HRSC 15 |
| GB/YB/JB/SY/NB (КНР) | 1Cr16Ni35, NS111, NS1404 |
