РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ
Материалы и марки
Обозначение материалов в соответствии с выбранными стандартами
| Стандарт | Группа материала № 41 | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| NF/AFNOR (ФРАНЦИЯ) | ||||||||||
| AISI/ASM/ASTM/SAE/UNS/AA (США) | A532 IA; Ni-Hard; F45000; Ni-Cr-Hc | A532 lllA 25% Cr | ||||||||
| BS (ВЕЛИКОБРИТАНИЯ) | Grade 2 B | Grade 3 E | ||||||||
| DIN (ГЕРМАНИЯ) | G-X 330 NiCr 4 2; EN-GJN-HV550; EN-GJN-HB510; EN-JN2039 | G-X 300 CrMo 27 1; EN-GJN-HB555(XCr23) | G-X 250 CrMoV 25 | |||||||
| Werkstoff (ГЕРМАНИЯ) | 0.9625; 5.5604 | 0.9655; 5.5610 | 1.419 | |||||||
| EN (ЕВРОПА) | EN-GJN-HB510; EN-JN2039 | EN-GJN-HB555(XCr23) | ||||||||
| GOST (РОССИЯ) | 20Ch25N20S2 | ChKh9N5; ChKh16M2; ChKh22; ChKh28D2; ChYu30; ChN3KhMDSha | ||||||||
| JIS (ЯПОНИЯ) | ||||||||||
| SS (ШВЕЦИЯ) | 0513-00 | |||||||||
| UNE (ИСПАНИЯ) | ||||||||||
| UNI (ИТАЛИЯ) | ||||||||||
| IS (ИНДИЯ) | ||||||||||
| KS (РЕСП. КОРЕЯ) | ||||||||||
| GB/YB/JB/SY/NB (КНР) | ||||||||||
