Материалы и марки
Обозначение материалов в соответствии с выбранными стандартами
| Стандарты | Группа материалов № 38 | Группа материалов № 39 | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| NF/AFNOR (ФРАНЦИЯ) | Z 40 C 13 | 55WC20; 55 WC 20 | Z 2 CN 18-10 M | X 160 CrMoV 12; Z 160 CDV 12 | ||||||
| AISI/ASM/ASTM/САЕ/UNS/АА (США) | A9; T30109 | S6; T41906 | 420 C; S41400; AMS 5615 | 414; S1; T41901 | K92890; K92710 | K93120; AMS 6512 | K93540; AMS 6514 | D2; T30402 | ||
| BS (ВЕЛИКОБРИТАНИЯ) | 420 S 45 | BS 1; T41901 | BS S162 | BD 2 | ||||||
| DIN (ГЕРМАНИЯ) | X39Cr13; X 38 Cr 13 | 60WCrV8; 60 WCrV 7 | X2NiCoMo18-8-5 | X2NiCoMo18-8-5; X2NiCoMo18-8-5 | X2NiCoMo18-8-5; X2NiCoMo18-8-5 | X2NiCoMo18-12; X2NiCoMoTi18-12-4 | X153CrMoV12; X155CrVMo12-1; X155 CrVMo 12 1 | |||
| Werkstoff (ГЕРМАНИЯ) | 1.4031 | 1.2550 | 1.6358; 1.6359 | 1.6354; 1.6359 | 1.6355; 1.6359 | 1.6356 | 1.238 | |||
| EN (ЕВРОПА) | X39Cr13 | 60WCrV8 | X2NiCoMo18-8-5 | X2NiCoMo18-8-5 | X2NiCoMo18-8-5 | X2NiCoMo18-8-5 | X153CrMoV12 | |||
| ГОСТ (РОССИЯ) | 40Ch13 | 6ChV2S; 5ChV2S | ||||||||
| JIS (ЯПОНИЯ) | SKD 10; SKD 11 | |||||||||
| SS (ШВЕЦИЯ) | 2310 | |||||||||
| UNE (ИСПАНИЯ) | F.520.A | |||||||||
| UNI (ИТАЛИЯ) | X 40 Cr 14 | 55 WCrV 8 KU | X 155 CrVMo 12 1 KU | |||||||
| IS (ИНДИЯ) | ||||||||||
| KS (РЕС. КОРЕЯ) | ||||||||||
| GB/YB/JB/SY/NB (КНР) | Cr12MoV | |||||||||
