Материалы и сорта
Обозначение материалов в соответствии с выбранными стандартами
Номер группы материалов: 35–36
| Стандарт | Материал 1 | Материал 2 | Материал 3 | Материал 4 | Материал 5 | Материал 6 | Материал 7 | Материал 8 | Материал 9 |
|---|---|---|---|---|---|---|---|---|---|
| NF/AFNOR (Франция) | KC 25 NW; KC 25 N 10 W 7 Fe | KD 27 DN | T-35 | T-40 | T-50 | ||||
| AISI/ASM/ASTM/SAE/UNS/AA (США) | Rene 220C | Udimet 700B | F75; AMS 5382E; AMS 5385D | A567; AMS 5385D; Cobalt Alloy 31; Cobalt #31 | R50250; Titanium Grade 1; ASTM GR. 1 | R50400; Titanium Grade 2; AMS 4902; AMS 4941; ASTM Gr. 2; TA2; TA3; TA4; TA5 | R50500; R50550; Titanium Grade 3; AMS 4900 | ||
| BS (Великобритания) | ANC 13; ANC 14; 3146.2 | TA1 | DTD 5023, DTD 5273 | ||||||
| DIN (Германия) | CoCr28MoNi | CoCr25NiW | G-CoCr28; G-CoCr28Nb | Ti 1; Ti 99.8; Titan Grade 1 | Ti 2; Ti 99.7 | Ti 3; Ti 99.6; Titan Grade 3 | |||
| Werkstoff (Германия) | 2.498 | 2.497 | 2.478; 2.478 | 3.7024; 3.7034; 3.7025 | 3.7035; 3.7036 | 3.7055; 3.7056 | |||
| EN (Европа) | G-CoCr28 | Ti 99.8 | Ti 99.7 | Ti 99.6 | |||||
| GOST (Россия) | VT1-00 | VT1-0 | |||||||
| JIS (Япония) | Class 2; Gr-1 | Class 2; Gr-2 | Class 3; Gr-3 | ||||||
| SS (Швеция) | |||||||||
| UNE (Испания) | Ti-PO1 | Ti-PO2; 38-711L-7001; 38-712L-7002 | |||||||
| UNI (Италия) | Ti1-Type 1 | Ti1-Type 2 | Ti1-Type 3 | ||||||
| IS (Индия) | |||||||||
| KS (Республика Корея) | |||||||||
| GB/YB/JB/SY/NB (КНР) | TA0 | TA1 | TA2 |
