Материалы и сорта
Обозначение материалов в соответствии с выбранными стандартами
Номер группы материалов: 33
| Стандарт | Материал 1 | Материал 2 | Материал 3 | Материал 4 | Материал 5 | Материал 6 | Материал 7 | Материал 8 | Материал 9 |
|---|---|---|---|---|---|---|---|---|---|
| NF/AFNOR (Франция) | NC 30 Fe | NU 30 | NC 22 FeD | NC 14 K 9 T 5 DWA | Z 8 NCDT 42 | NC 19 KDT | NU 30 | NC 16 FeT | |
| AISI/ASM/ASTM/SAE/UNS/AA (США) | Inconel 690; N06690 | Monel 400; N04400 | Hastelloy X; Inconel HX; N06002; AMS 5754; AMS 5536 | Inconel 617; N06617; AMS 5887 | Nimonic 90; N07090; AMS 5829 | Haynes 214; NO7214; AMS 5712; AMS 5800 | Hastelloy B2; N10665 | Inconel 600; N06600; AMS 5665 | Monel R-405; N04405 |
| BS (Великобритания) | NA 13; ANC 18 | NA 13 | HR 6; HR 204 | HR 2; HR202; HR 402; HR 501; HR 502; HR 503 | HR 401 | HR 401 | NA 14 | ||
| DIN (Германия) | NiC29Fe | NiCu30Fe | NiCr30FeMo; NiCr22Fe18Mo; NiCr21Fe18Mo9 | NiCr23Co12Mo; NiCr 20 Co 18 Ti | NiCr20Co18Ti | NiCr19Co11MoTi; NiCr 19 CoMo; SG(UP)-NiMo27 | NiMo28; EL-NiM29 | NiCr15Fe8; NiCu30Fe; NiCr 15 Fe | |
| Werkstoff (Германия) | 2.464 | 2.4360; 2.4361 | 2.4603; 2.4665 | 2.4663a | 2.4632; 2.4969 | 2.4646 | 2.4617; 2.4616; 2.4615 | 2.4360; 2.4361; 2.4816 | 2.4973 |
| EN (Европа) | NiCr30FeMo | NiCr20Co18Ti | NiCr19Co11MoTi | NiMo28 | NiCr15Fe8 | ||||
| GOST (Россия) | ChN78T | ||||||||
| JIS (Япония) | YNiMo-7 | ||||||||
| SS (Швеция) | |||||||||
| UNE (Испания) | |||||||||
| UNI (Италия) | |||||||||
| IS (Индия) | |||||||||
| KS (Республика Корея) | |||||||||
| GB/YB/JB/SY/NB (КНР) | NS315 | GH22; GH334; GH536; GH739; SG-5 | GH4037 | GH141 | NS322 | NS312 |
