РУКОВОДСТВО ПОЛЬЗОВАТЕЛЯ
МАТЕРИАЛЫ И МАРКИ
Обозначение материалов в соответствии с выбранными стандартами
| Стандарты | Номер группы материалов | ||||||||
|---|---|---|---|---|---|---|---|---|---|
| 11 | 11 | 11 | 11 | 11 | 12 | 12 | 12 | 12 | |
| NF/AFNOR (ФРАНЦИЯ) |
Z 2 CN 18-10 M | Z 13 CF 17 | Z 12 CAS 18 | Z 8 CD 17-01 | |||||
| AISI/ASM/ASTM/SAE/UNS/AA (США) |
M62, T11362 | K92710 | K92890; AMS 6512 | K93120; AMS 6514 | K93540; AMS 6515 | 430 F; S43020 | 434; S43400 | ||
| BS (ВЕЛИКОБРИТАНИЯ) |
BS S162 | 434 S 17 | |||||||
| DIN (ГЕРМАНИЯ) |
X2NiCoMo18-9-5; X2NiCoMo18-8-5 | X2NiCoMo18-8-5; X2NiCoMo18-8-5 | X2NiCoMo18-12; X2NiCoMoTi18-12-4 | X12CrMoS17; X 12 CrMoS 17 | X10CrAlSi18; X10CrAl18; X10CrAl13; X 10 CrAl 13 | X10CrAlSi13 | X6CrMo17-1; X 6 CrMo 17 1 | ||
| Werkstoff (ГЕРМАНИЯ) |
1.636 | 1.6358; 1.6359 | 1.6354; 1.6359 | 1.6355; 1.6356 | 1.4104 | 1.4742 | 1.4724 | 1.4113 | |
| EN (ЕВРОПА) |
HS 6-10-2 | X2NiCoMo18-8-5 | X2NiCoMo18-8-5 | X2NiCoMo18-8-5 | X12CrMoS17 | X10CrAlSi18 | X10CrAlSi13 | X6CrMo17-1 | |
| GOST (РОССИЯ) |
15Ch18SJu | 10Ch13SJu | |||||||
| JIS (ЯПОНИЯ) |
SUS 430 F | SUS 21 | SUS 434 | ||||||
| SS (ШВЕЦИЯ) |
2383 | 2325 | |||||||
| UNE (ИСПАНИЯ) |
F.3413 | F.3113; X 10 CrAl 18 | F.3152; X 10 CrAl 13 | F.3116 | |||||
| UNI (ИТАЛИЯ) |
X 10 CrS 17 | X 10 CrAl 12 | |||||||
| IS (ИНДИЯ) |
|||||||||
| KS (РЕСПУБЛИКА КОРЕЯ) |
STS 434 | ||||||||
| GB/YB/JB/SY/NB (КНР) |
Y1Cr17 | Cr17 | 1Cr13SiAl | 1Cr17Mo | |||||
